Mercury Sable Brake Line Set 2002 BLF-100-SS2C
Non-ABS w/Rear Drum Brakes
Mercury Sable Brake Line Set 2002 BLF-100-SS2C
Non-ABS w/Rear Drum Brakes
Delivery Time & Rates
Install this pre bent 2002 Mercury Sable brake line set in no time!
Brake Line Set Stainless Steel Mercury Sable Non-ABS w/Rear Drum Brakes for 3.0L engines
Please Note: Before installing your brake line, a shipping bend will need to be removed from the lines labeled BLF100-05A-SS, BLF100-05B-SS, BLF100-06A-SS, and BLF100-06B-SS. See the video below on how to remove the shipping bend
- Weight: 5
- Installation Instructions
Master Cylinder Primary Line runs from Rear Port of Master Cylinder to Junction Block, Master Cylinder Secondary Line runs from Front Port of Master Cylinder to Junction Block, Left Front Brake Line runs from Junction Block to Left Front Brake Hose Connection, Left Rear Brake Line runs from Front of Left Rear Combination Valve to Left Rear Wheel Cylinder, Right Rear Brake Line runs from Front of Right Rear Combination Valve to Right Rear Wheel Cylinder
1 Master Cylinder Primary Line 3/16", 1 Master Cylinder Secondary Line 3/16", 1 Left Front Brake Line 3/16", 1 Left Rear Brake Line 3/16" (3 easy to install sections), 1 Right Rear Brake Line 3/16" (5 easy to install sections), Does NOT include Right Front Brake Line, Left Rear Brake Hoses, and Right Rear Brake Hoses
Lines are constructed from Stainless Steel tubing for rust protection with original equipment end forms and fittings and are CNC (Computer Numerically Controlled) bent for an easy precise installation
